WS-C2960X-48LPS-L Overview
Cisco Catalyst 2960X series 48 ports LAN Base stackable switch delivers Power over Ethernet Plus(PoE+) that supports up to 370W of PoE budget for 12 ports with 30W per port, or 24 ports with 15.4W per port or 48 ports with 7.4W per port.
Quick Specs
Figure 1 shows the appearance of WS-C2960X-48LPS-L.
Product Details
Figure 1 shows the stackable capacity.
This C2960X switch delivers stackable capacity that supports up to 8 switches stacking with same 2960-X LAN base series. It also can stack up to 4 switches stacking when mixed with 2960-S LAN base series switches.
The Accessories
Table 1 shows some accessories of WS-C2960X-48LPS-L.
Models | Description |
C2960X-STACK | Catalyst 2960-X FlexStack Plus Stacking Module |
CAB-STK-E-0.5M | Cisco FlexStack Stacking Cables |
GLC-LH-SMD | Cisco GLC-LH-SMD 1000BASE-LX/LH SFP transceiver module, MMF/SMF, 1310nm, DOM |
GLC-SX-MMD | 1000BASE-SX SFP transceiver module, MMF, 850nm, DOM |
CAB-CONSOLE-RJ45 | Console Cable 6ft with RJ45 and DB9F |
CAB-CONSOLE-USB | Console Cable 6 ft with USB Type A and mini-B |
WS-C2960X-48LPS-L Specification
WS-C2960X-48LPS-L Specification |
|
Enclosure type | Rack-mountable – 1U |
Feature Set | LAN Base |
Uplink Interfaces | 4 x 1G SFP |
Ports | 48 x 10/100/1000 + 4 x 1G SFP |
Network management Interface | 10/100 Mbps Ethernet (RJ-45) |
Available PoE Power | 370W |
Forwarding bandwidth(Gbps) | 108Gbps |
Maximum stacking number | 8 |
Stack Bandwidth | 80 G |
Forwarding Performance | 107.1Mpps |
Switching bandwidth | 216Gbps |
Maximum active VLANs | 1023 |
MAC Address Table Size | 16K (default) |
CPU | APM86392 600MHz dual core |
RAM | 256 MB |
Flash Memory | 64 MB |
Status Indicators | Per-port status: Link integrity, disabled, activity, speed, and full duplex System status: System, RPS, Stack link status, link duplex, PoE, and link speed |
Expansion / Connectivity | |
Console ports | USB (Type-B), Ethernet (RJ-45) |
Stacking cable | Optional |
Power Redundancy | Option (PWR-RPS2300) |
Voltage range (Auto) | 110V-240V |
Power Consumption Operational | 0.49KVA |
Miscellaneous | |
Width | 17.5 Inches (44.5 cm) |
Depth | 14.5 Inches (36.8 cm) |
Height | 1.75 Inches (4.5 cm) |
Weight | 12.9 lb (5.8 Kg) |
Package Weight | 23.48 lb (10.65 Kg) |
Rack Mounting Kit | optional |
MTBF in hours | 276,870 |
Compliant Standards | ● IEEE 802.1D Spanning Tree Protocol ● IEEE 802.1p CoS Prioritization ● IEEE 802.1Q VLAN ● IEEE 802.1s ● IEEE 802.1w ● IEEE 802.1X ● IEEE 802.1ab (LLDP) ● IEEE 802.3ad ● IEEE 802.3af and IEEE 802.3at ● IEEE 802.3ah (100BASE-X single/multimode fiber only) ● IEEE 802.3x full duplex on 10BASE-T, 100BASE-TX, and 1000BASE-T ports● IEEE 802.3 10BASE-T ● IEEE 802.3u 100BASE-TX ● IEEE 802.3ab 1000BASE-T ● IEEE 802.3z 1000BASE-X ● RMON I and II standards ● SNMP v1, v2c, and v3 ● IEEE 802.3az ● IEEE 802.1ax |
System software / license | |
System software | IOS LAN BASE |
license | NERGY-MGT-100-K9, EW-DO-100-DE |
features | ●Jumbo Frames
●VLANS ●Voice Vlan ●VTPv2 ●CDPv2 ●LLDP ●802.3ad LACP ●PVST/PVST+ ●802.1W/802.1S ●Port Fast/Uplink Fast ●port CoS Trust and Override ●Scheduling ●Priority Queuing ●Configure CoS Priority Queues ●Weighted Tail Drop ●DSCP transparency |
Network security | ●SSH, SSL and SCP
●RADIUS and TACACS+ ●SNMPv3 crypto ●802.1x ●802.1x Accounting / MIB ●802.1x w/ port security ●802.1x w/Voice VLAN ●802.1x Guest VLAN ●802.1x VLAN assignment ●802.1x MAC-Auth Bypass ●BPDU/Root Guard ●Port Security ●Private VALN Edge ●Storm Control ●Block unknown unicast and multicast ●IGMP Snooping ●IGMP Filter/Throttle |
Management and Troubleshooting | ●Auto-MDOX
●TDR ●UDLD ●IP SLA Responder ●layer 2 / IP Traceroute ●SPAN ●RSPAN ●Express Setup ●Device Manager ●Cisco Network Assistant ●Smartports + Advisor ●Troubleshooting Advisor ●Drag-and-drop Cisco IOS Upgrade ●IP Address DHCP ●Autoinstall with saved configuration ●Configuration Replace ●DHCP Auto Image Upgrade ●DHCP Port Based Allocation ●Error Disable MIB |
Environmental Ranges | |
Operating temperature up to 5000 ft (1500 m) | 23ºF to 113ºF
(-5ºC to 45ºC) |
Operating temperature up to 10,000 ft (3000 m) | 23ºF to 104ºF
(-5ºC to 40ºC) |
Short-term exception at sea level* | 23ºF to 131ºF
(-5ºC to 55ºC) |
Short-term exception up to 5000 feet (1500 m)* | 23ºF to 122ºF
(-5ºC to 50ºC) |
Short-term exception up to 10,000 feet (3000 m)* | 23ºF to 113ºF
(-5ºC to 45ºC) |
Short-term exception up to 13,000 feet (4000 m)* | 23º to 104ºF
(-5ºC to 40ºC) |
Storage temperature up to 15,000 feet (4573 m) | -13º to 158ºF
(-25º to 70ºC) |
Operating altitude | Up to 10,000 Feet
(Up to 3000 Meters) |
Storage altitude | Up to 13,000
(Up to 4000 Meters) |
Operating relative humidity | 10% to 95% noncondensing |
Storage relative humidity | 10% to 95% noncondensing |
